SAXSShell

SAXSShell is a workflow-oriented toolkit for comparing molecular dynamics structures against small-angle X-ray scattering (SAXS) data.

In plain language, the main goal is to help you answer a solvation-structure question: "which cluster populations, representative structures, and model choices from my simulation best match the experimental SAXS signal?"

The repository combines:

• Qt desktop applications for interactive use
• source-checkout module launches for reproducible batch runs
• Python workflow classes that mirror the same operations for notebooks and scripts

The project is aimed at researchers who need to move from trajectory files to cluster populations, distribution analysis, SAXS component building, Prefit screening, and Bayesian fitting without constantly switching tools.

Who this documentation is for

This site is organized around tasks:

• users preparing raw MD trajectories for a new SAXSShell project
• users preparing a new SAXS project from cluster folders
• users running SAXS Prefit and pyDREAM refinement
• users maintaining or extending the template system
• contributors working on the codebase itself

If you want a quick starting path, begin with installation, then learn how to process your MD trajectories and create a project folder for the SAXSShell session:

• Installation
• MD Extraction and Cluster Preparation
• Quickstart
• Project Setup

Main workflow

The current repo supports an end-to-end path that usually looks like this:

1. Inspect and split trajectories with mdtrajectory.
2. Optionally convert XYZ frames to residue-aware PDB files with xyz2pdb.
3. Extract clusters with clusters.
4. Analyze time-dependent cluster populations with clusterdynamics.
5. Optionally predict larger clusters and representative predicted structures with clusterdynamicsml.
6. Measure bond and angle distributions with bondanalysis.
7. Optionally compute project-backed representative structures with the full Representative Structures UI or the beta run-file based representativefinder source-module path.
8. Optionally compute project-backed Debye-Waller factors from sorted PDB cluster folders with Debye-Waller Analysis. This path is currently in testing and should be treated cautiously because the linked Compute Debye-Waller Factors (beta) workflow still has a known bug.
9. Optionally compute trajectory-averaged PDFs and partial PDFs with pdfsetup.
10. Create a dedicated SAXSShell project folder, launch the main application from the source checkout, create or load a computed distribution in Project Setup, and choose how SAXS components will be prepared.
11. Build components with one of the supported modes: No Contrast (Debye), Contrast (Debye), 1D Born Approximation (Average), or 3D FFT Born Approximation.
12. Refine the project in SAXS Prefit and, if needed, run pyDREAM.
13. Use the resulting distributions and selected structures in downstream tools such as the fullrmc workflow.

Documentation map

Getting started

Use this section if you are setting up the software for the first time or want to create your first project quickly.

User guide

Use this section when you already know the rough workflow and need details about GUI tabs, computed distributions, component-build modes, file layout, template behavior, export paths, or the supporting applications that feed data into the main SAXS UI.

The user guide is split into:

• Main UI workflow elements for the SAXSShell application and its project, computed distributions, Prefit, DREAM, template, and export behavior
• Supporting applications grouped the same way as the main Tools menu: MD Extraction, Structure Analysis, Cluster Dynamics, PDF, Visualization, SAXS Calculation Preview, X-ray Toolkit, and (beta)

Tutorials

Use this section for longer, task-based walkthroughs that connect several tools in sequence. These pages are still early drafts rather than complete tutorials.

API

Use this section if you want the shortest route to the reusable workflow classes. It is currently a provisional overview, not a complete API reference.

Development

Use this section if you are contributing code, working on CI, or changing the documentation site itself. These contributor notes are still being built out.

Scope notes

The SAXS workflow in this repository is active and evolving. The documentation focuses on features that are already represented in the current codebase. When exact behavior is still evolving, the docs call that out explicitly instead of guessing.

Note

SAXSShell is in the process of being renamed from SAXShell. During this transition, some internal package paths, CLI names, saved-settings namespaces, or compatibility references may still use saxshell or SAXShell even though the front-facing documentation and UI are being updated to SAXSShell.
